Calibration and Settings Settnings menu Settings are entered and certain calibrations are carried out in the Settings menu. Navigate through the menus by turning and depressing the control panel wheel. It is always possible to return to the menu above by pressing . Repeated presses or holding the button down for >3 seconds will return to the main menu. NOTICE! Only installed functions are shown in the settings menu. p0005184
1 Turn clockwise until Settings is shown on the display. 2 Press the wheel to access the settings menu. 3 Navigate by turning the wheel. P0001015
Depth Alarm Setting the depth alarm for the Volvo Penta echo sounder. The setting need only be entered at one display, at one station. 1 Activate the station. 2 Turn until Depth Alarm is shown in the settings menu. Press the wheel to reach the submenu.
P0001028
3 Depth Alarm, press the wheel to switch the function on or off.
P0001027
