Instruments and Controls This chapter describes the instruments, panels and controls Volvo Penta sells for your engine. If you would like to complement your instrumentation, or if your boat is equipped with instruments not described here, we ask that you contact your Volvo Penta dealer.
Ignition Lock The start keys are supplied with a plate bearing the start code to be used when ordering spare keys. Keep the code beyond the reach of unauthorized people. S 0 I II III
= = = = =
Stop position. The key can be inserted or removed. Operating position. System voltage is connected. Not used. Start position. Start motor is engaged.
Read the starting instructions in chapter Starting page 28 to ensure you use the correct start procedure.
Start/Stop Panel The start/stop panel is used for starting and stopping the engine. To start the engine it is necessary for the start key at the main station to be in the ”I” operating position. The engine can only be stopped from an activated control panel. Read the starting instructions in chapter Starting page 28 to ensure you use the correct start procedure.
