6 Maintenance
Draining of water from the water separator/fuel filter Every 100 operating hours.
8 Drain fuel filter
Danger Do not smoke when draining off water and sediment. Keep flame and sources of ignition out of the area. Remove spilled fuel and litter before you start the engine.
The drain plug is on the bottom of the filter.
• Unscrew the drain plug.
• First disconnect the connection on the drain plug. The locking spring must be pushed in to release the connection.
• Allow the water to drain out and then close the drain plug. • Put the connection back on the drainplug. The locking spring must be pushed in to allow the connection to be put back on the drain plug.
41
