Gearbox oil level check
4 Maintenance
Every 500 operating hours.
VD00468
VD00469
28 Unscrewing the dipstick
29 Oil level check
• Unscrew the dipstick out of the gearbox housing.
• Check the oil level by cleaning the dipstick and lowering it into the hole, without screwing it in. The oil level must between the two marks on the dipstick. If necessary top up by pouring oil in the dipstick hole. For oil type and specification see page 70.
40
Vetus engines are normally equipped with ZF-Hurth gearboxes. Consult the supplied Owners Manual for more details about care and maintenance. In case your engine is equipped with another brand of gearbox follow the instructions given in the supplied owners manual for changing oil and other care and maintenance.
