Chapter 1
System Specifications Features Performance Aspire 9400 / TravelMate 5600 Series Intel® Centrino® mobile technology, featuring: T
Intel® Pentium® M processor 740/750/760/770/780 (2 MB L2 cache, 1.73/1.86/2/2.13/2.26 GHz, 533 MHz FSB)
T
Intel® Pentium® M processor 735 (2 MB L2 cache, 1.70 GHz, 400 MHz FSB) or higher
T
Intel® 915PM/915GM Express chipset
T
Integrated Intel® PRO/Wireless 2200BG network connection (dual-mode 802.11b/g) Wi-Fi CERTIFIEDTM solution, supporting Acer SignalUpTM wireless technology
Aspire 7100 / TravelMate 5100 Series With no Centrino® mobile technology, featuring: T
Intel® Celeron® M processor 370/380/390 (1 MB L2 cache, 1.50/1.60/1.70 GHz, 400 MHz FSB) or higher
T
Mobile Intel® 910GML Express chipset
T
Integrated Acer InviLinkTM 802.11b/g Wi-Fi CERTIFIED solution, supporting Acer SignalUpTM wireless technology
Core Logic T
North Bridge + South Bridge: T
915GM + ICH6M
T
915PM + ICH6M
T
910GML + ICH6M
Memory T
DDR2 400/533 SDRAM
T
Two soDIMM slots, 128MB to 1GB per slot
T
Maxium memory up to 2GB with two 1GB SODIMMs
T
512KB system/video BIOS in flash ROM; shadow RAM supported
T
Dual Channel support
T
17 WXGA TFT LCD, 1440 x 900 pixel resolution , supporting simultaneous multi-window viewing on dual displays via Acer GridvistaTM
T
Nvidia® GeForceTM Go 7300 graphics with 256 MB of VRAM (128 MB of dedicated GDDR2 VRAM; 128 MB of shared system memory), supporting Microsoft® DirectX® 9.0, Shader Model 3.0, OpenEXR High Dynamic Range (HDR) technology, Nvidia® TurboCacheTM, Nvidia® PowerMizerTM 6.0, PCI Express®, or
T
Intel® 915GM integrated 3D graphics, featuring Intel® Graphics Media Accelerator 900, up to 128
Display
Chapter 1
1
