LCD Disassembly
63
1.
Remove the eight caps on the LCD bezel.
2.
Remove the eight screws securing the LCD bezel.
3.
Remove the LCD bezel from the LCD module. Please release all latches as shown. Press the latch a little bit to remove the LCD bezel.
4.
Remove the screw securing the inverter board.
5.
Pull the inverter board and turn it over, disconnect the cables from the inverter board as shown, and remove the inverter board.
6.
Remove the four screws securing the LCD panel.
7.
Remove the LCD panel from the LCD cover.
8.
Remove the left and right LCD hinge from the LCD cover.
Chapter 3
