SERVICING YOUR OUTBOARD MOTOR Portable Fuel Tank and Tank Filter Cleaning (optional equipment)
Fuel Tank
Fuel Tank Filter 5 mm SCREW (4)
CONNECTOR GASKET
Gasoline is highly flammable and explosive. You can be burned or seriously injured when handling fuel. • Stop the engine and keep heat, sparks, and flame away. • Handle fuel only outdoors. • Wipe up spills immediately.
FUEL HOSE (standard equipment)
Empty the portable fuel tank into an approved gasoline container. Use a funnel to avoid spilling fuel. Rinse the fuel tank with nonflammable solvent to remove any accumulated sediment.
FUEL TANK FILTER FUEL TANK FILTER JOINT (Fuel Hose Connector)
1. Remove the four 5 mm screws using a flat screwdriver, and then remove the fuel hose connector and fuel tank filter from the tank. 2. Clean the filter in nonflammable solvent. Inspect the fuel tank filter and the connector gasket. Replace them if damaged. 3. Reinstall the filter and hose connector in the fuel tank. Tighten the four 5 mm screws securely.
97
