SERVICING YOUR OUTBOARD MOTOR REFUELING Portable Fuel Tank (optional equipment)
VENT KNOB
FUEL GAUGE OPEN
FUEL TANK CAPACITY: 6.6 US gal (25 L)
Check the fuel gauge and refill the tank when necessary. Remove the fuel tank from the boat for refueling.
2. Turn the fuel filler cap counterclockwise so that it touches the pressure relief tab. FUEL FILLER CAP
1. Turn the vent knob counterclockwise all the way to open the vent.
PRESSURE RELIEF TAB
88
