SERVICING YOUR OUTBOARD MOTOR Lubrication Points Apply TOHATSU Marine grease to the parts shown below:
THROTTLE ARM/ LINK/PIVOT/PLATE
THROTTLE ROD/LINK
Lubrication interval: After the first 20 hours or 1 month, then every 100 hours or 6 months (refer to the MAINTENANCE SCHEDULE on page 74).
TILT BRACKET
Apply anticorrosion oil to pivot surfaces where grease cannot penetrate.
TILT SHAFT
PROPELLER SHAFT
SWIVEL CASE
THRUST RECEIVER
Apply corrosion inhibitor to all areas under the engine cover and any exposed metal surfaces except the belts.
86
