SERVICING YOUR OUTBOARD MOTOR Spark Plug Service <Standard spark plug>
6 × 20 mm FLANGE SH BOLT
RECOMMENDED SPARK PLUG: ZFR6K-9E (NGK)
CONNECTOR LOCK TAB IGNITION COIL
Incorrect spark plugs can cause engine damage. See page 85 for instructions of handing the iridium spark plugs (optional parts). 1. Disconnect the battery negative (-) terminal. 2. Unlock and remove the engine cover (p.77).
PLUG MAINTENANCE COVER
3. Remove the 6 20 mm flange SH bolt and remove the plug maintenance cover.
6 × 25 mm FLANGE BOLT
4. Remove the 6 25 mm flange bolt. Disconnect the connector by pushing the lock tab and remove the ignition coil.
83
