OPERATION During the warm-up period, check the oil pressure indicator (p.35), overheat indicator (p.35), and cooling system indicator (p.36). If the indicators show any abnormal condition, immediately stop the engine and determine the cause of the problem. Refer to TAKING CARE OF UNEXPECTED PROBLEMS on p.115-117. 6. If the fast idle button was used to warm up the engine, gradually return the control lever to the N (neutral) position as the engine warms up.
EMERGENCY STARTING If the battery is discharged or the starter motor is inoperative, you can start the engine manually using the emergency starter rope supplied with the outboard motor.
6 × 25 mm FLANGE BOLT
ALTERNATOR COVER
6 mm WASHER CLAMP HOOKS CLAMPS
BREATHER TUBE
UNLOCK ENGINE COVER LATCHES (front/rear)
1. Turn the ignition switch key to the OFF position (p.62).
CLAMP (on the silencer case)
3. Release the breather tube from the four clamps. 4. Remove 6 25 mm flange bolt and 6 mm washer, and then remove the alternator cover.
2. Unlatch the engine cover latches and remove the engine cover.
