CONTROLS AND FEATURES
F (FORWARD)
N (NEUTRAL) 30° 30° SHIFT
MINIMUM THROTTLE OPENING
Fast Idle Lever R (REVERSE)
FAST IDLE LEVER
SHIFT MINIMUM THROTTLE OPENING MAXIMUM
MAXIMUM GEARSHIFT/THROTTLE CONTROL LEVER
Moving the control lever 30° from N (neutral) selects the gear, and further movement increases engine speed. The control lever automatically locks itself in the N (neutral) position. To move the lever out of the N (neutral) position, you must squeeze the neutral release lever on the underside of the lever handle.
20
A friction adjuster near the base of the control lever(s) adjusts the operating resistance of the control lever(s). Refer to p.64. Less friction allows easier control lever movement. More friction helps to hold a steady throttle setting while cruising.
Use the fast idle lever to accelerate engine warm-up after starting the engine. Do not use the fast idle lever when starting the engine. See page 51 for engine warm-up instructions.
