TAKING CARE OF UNEXPECTED PROBLEMS 4. Remove the old fuse by removing two 5 mm screws. 5. Install a new fuse with the “70 A” mark downward.
OIL PRESSURE INDICATOR TURNS OFF AND ENGINE SPEED IS LIMITED Side-Mount Type OIL PRESSURE INDICATOR
ACG FUSE RATING: 70 A 6. After finishing replacement, install the fuse case lid with its hook toward the engine side.
(GREEN)
7. Be sure the fuse case lid is securely locked.
BUZZER
8. Reinstall the engine cover. 9. Reconnect the battery. A spare fuse is located in the reverse side of the fuse case lid and tightened with two 3 mm screws. When the new fuse is set as a spare fuse on the reverse side of the fuse case lid, set the fuse so that you can see the “70 A” mark on it.
Panel-Mount/Top-Mount Types OIL PRESSURE INDICATOR
(GREEN)
If oil pressure becomes low, the oil pressure indicator will turn off, and the engine protection system limits engine speed. If you are at cruising speed, engine speed will decrease automatically. The oil pressure indicator is also equipped with a buzzer that sounds when the oil pressure indicator turns off. Low oil pressure may be the result of a low engine oil level, or there may be a problem with the engine lubrication system. If the throttle is closed suddenly after full throttle operation, engine speed may drop below the specified idle rpm, and that could activate the engine protection system momentarily.
BUZZER
115
