Tigercat H860C/H870C/LH870C Harvester
Safety
SERVICING SAFETY PRECAUTIONS continued
DISCONNECT THE 6 PIN PLUG FROM THE BACK OF THE DISPLAY MODULE
•
• ••
822C-05
Disconnect the IQAN display 6 pin connector and the control module 42 pin connector.
DISCONNECT THE TWO MULTI-PIN PLUGS FROM THE ENGINE WIRING
870-D01
IQAN DISPLAY DISCONNECT
EARLIER MACHINES (860*1501 TO 860*1699, 870*1501 TO 870*1699)
••
Disconnect the engine ECM (Electronic Control Module) by unplugging the multi-pin connectors from the left side of the engine.
DISCONNECT THE 42 PIN PLUG FROM THE XS MODULE
• • •
••
DISCONNECT 4 PIN ENGINE POWER CONNECTOR 822C-34
• DISCONNECT THE TWO MULTI-PIN PLUGS FROM THE ENGINE ECM
ENGINE ECM DISCONNECT -LEFT SIDE OF ENGINE 822C-04
LATER MACHINES (860*1700 AND UP, 870*1700 AND UP)
IQAN XS MODULE DISCONNECT
IMPORTANT
Disconnect the engine ECM (Engine Control Module) by unplugging the four pin engine power connector and the two multipin connectors from the left side of the engine.
24 VOLT ELECTRICAL SYSTEM
1.16
