Safety
Tigercat H845C/LH845C Harvester
SAFETY INTERLOCK SWITCH ON FRONT DOOR:
4. DO NOT allow people or other pieces of equipment near the harvesting operation.
The front door is equipped with a safety interlock switch to prevent the machine from being operated while the front door is open (pilot system is shut off). INTERLOCK SWITCH
5. DO NOT turn on harvesting head until machine is at the harvesting site. 6. Use only prearranged and approved signalling practices.
ACTUATOR ON DOOR
WARNING INTERLOCK SWITCH (FRONT DOOR)
822C-251
DO NOT open an escape hatch or the cab doors to increase ventilation when operating the machine. Keep the cab doors closed when driving or steering the machine to prevent accidental entry of branches and debris into the cab. Keep the cab doors closed and use seat belt when driving or steering the machine to prevent being thrown from the operator's cab. Secure loose items in the cab. Prior to commencing work, check all equipment controls to ensure that the machine responds correctly. Make sure that all safety screens and guards including the skylight are installed and properly secured. Always rest the harvesting head on the ground when operation is stopped, regardless if the engine is running or shut off. Operate the machine only from a seated position in the operator’s seat. Watch for ground hazards such as metal debris, wire fencing or rocks. When travelling, position harvesting head and boom so as not to impair vision. If vision is limited by dust, smoke, fog, rain or snow, stop the machine until visibility is restored. If saw guard has been installed, DO NOT REMOVE until at the cutting site. Remove guard before starting engine.
Push the red PILOT OFF switch and confirm the PILOT OFF Icon is activated (yellow) on the MD3 display before removing seat belt. DO NOT use the front door interlock switch to turn pilot OFF. NOTE: Engine can be started but the machine functions cannot be operated with the door open.
WARNING The door safety interlock switch and the pilot reset switch are a safety feature and their function must not be compromised in any way. To operate: Close the front door and press the green PILOT ON RESET switch . The PILOT ON icon will be activated (green) on the MD3 display. Once the safety interlock system has been activated, the safety of both the operator and all persons outside the cab becomes the responsibility of the operator.
WARNING
1. When the engine is running, DO NOT allow anyone in areas of the machine where they may be crushed by moving components.
CAUTION DO NOT open cab doors or window screens when cab is on a slope. The doors and screens are heavy and could swing out with considerable force. Anyone in the path of swing could be injured. Anyone opening the door or screen and holding on to it could be pulled out of the cab and injured.
2. Maintain a safe operating distance between the machine and other personnel. NEVER operate the boom or harvesting head over the heads of bystanders. 3. NEVER travel near coworkers or other pieces of equipment with harvesting head running. 1.12
