CHECKING THE CHARGING CIRCUIT
FRANÇAIS
1 – Static control values (engine off) 450 SEF-R. Battery voltage > 12.5V. A – Stator windings resistance values :
Y1-Y2 Y2-Y3
0.44Ω±10%
Y1-Y3
B – Resistance of the engine speed sensor : 117Ω±10% Check that there is no continuity between the windings and the mass of the motorbike. 2 – Dynamic control values : Engine speed sensor : 1.7V MIN/300 RPM. 120V MAX/10000 RPM. Tension regulator : Alternative (AC 200V caliber). Idle : 22V ±2V. At 6000 RPM : 77V±3V. Direct : On regulator output (DC 20V caliber). At 4000 RPM : 14.6V + Red/White, - Green.
68
450 SEF-R
