Component Procedures Control Handle
3. Connect the wiring harness connectors and install new cable ties where previously located. NOTE: If the truck is a Cold Storage Unit, apply an ample amount of sealing compound (P/N 990-564) where wires enter plugs or receptacles. The amount applied should be enough to prevent moisture from entering the connector. Disconnect connectors to apply compound both internally and externally. Avoid sealing compound on pin contact area. 4. Install the lower control handle cover with the four hex head cap screws removed previously. 5. Install the control handle bottom cover with the four hex head cap screws removed previously. 6. Connect the battery connector and turn the key switch ON. 7. Test the operation of the truck.
Control Handle Stem Removal 1. Turn the key switch OFF and disconnect the battery connector. 2. Remove the four hex head cap screws securing the lower control handle cover. 3. Disconnect the wiring harness connectors. See Figure 6-20. Note the position of cable ties holding harnesses and cables. When reassembling, attach new cable ties in the same locations.
CAUTION
Before removing the chain master link in the next step, make sure you are holding the handle. When the master link is removed, the handle will fall. 4. Pull the handle down to operating range. Insert a wire or punch through a chain link close to the handle (or use a pair of locking pliers to grasp the chain close to the handle).
