Raymond® Walkie Pallet Truck Maintenance Manual
Component Procedures Main ON/OFF Switch
Main ON/OFF Switch A Main ON/OFF switch (SW13) is provided on the gauge console. See Figure 6-12. In the OFF position (O), battery power to all control functions is interrupted. In the ON position (I), battery potential is provided to all control functions via the key switch.
Main ON/OFF Switch
Gauge Console
Inspection 1. With the battery plugged in and the Main ON/OFF switch in the ON position, battery voltage B+ should be present on both terminals of the switch. 2. Test the Main ON/OFF switch with an ohmmeter after disconnecting the battery and removing the wires from the switch terminals. In the OFF position, the ohmmeter should read greater than 1 megohm, and in the ON position, the ohmmeter should read less than 1 ohm. If not, replace the switch.
1581 004.tif
Figure 6-12: Main ON/OFF Switch Location
Removal 1. Disconnect the battery connector. 2. Remove the tractor cover. 3. Remove the gauge console from the electrical panel. 4. Disconnect the wires from the switch. 5. Remove the Main ON/OFF switch.
Installation 1. Install the new Main ON/OFF switch. 2. Connect the wires to the new Main ON/OFF switch terminals. 3. Re-install gauge console onto electrical panel. 4. Reconnect the battery connector and check operation. 5. Install the tractor cover.
PDMM-0100 Issued: 5/21/01
6-25
