Raymond® Walkie Pallet Truck Maintenance Manual
Component Procedures Wiring Harness
Wiring Harness All wires in the harness are marked every 1 to 1.5 in. (2.54 to 3.81 cm) with a wire identification number. These numbers correspond to wire identification given in the schematic. See “Schematics” on page A-9.
Terminology The term “connector JPx” means a mated connector consisting of two connector halves. One half contains male connectors, or pins (P); the other half contains female connectors, or jacks (J). When you disconnect a mated JP connector, you will have two connector halves. The individual connector halves are designated by “Jx” and “Px.” For example, connector JP2 is the mated connector in the control handle. J2 represents the jack connections. P2 represents the pin connections. To locate electrical connectors on the truck refer to the electrical schematic located in the Appendix or see “Electrical Connector Locator Chart” on page 5-12.
