Clutch OFF (for reference)
Clutch ON 650 - BOOrpm
I
Model
I I
NS40D NSSOD
I
850 - 900 rpm
Maximumspeed range rat f”” thJntt,e, 4.500 - 5.500 rpm
I
5.000 - 5.700 rmn
OVERHEAT BUZZER (OPTIONAL) When the coolant temperature exceeds the specified setting during operation, the overheat buzzer will sound and engine speed will decrease. When this occurs, immediately return the shift or the control lever to Neutral. Check that cooling water is discharging pmperly from the inspection port, and then stop the engine. Check the gear case exterior for accumulation of weeds or foreign particles. Remove weeds, foreign particles, etc. as required. EF and EFO types Check that the overheat buzzer does not sound when the main switch is turned “ON” before starting the engine. EP type Check that the overheat buzzer does not sound when the main switch is turned “0” and the control lever is shifted to FORWARD 01 REVERSE before starting. CAUTION: If the buzzer sounds sporadically atier starting the engine, consult the nearest Nissan marine dealer.
FORWARD AND REVERSE OPERATION F and EFO types Forward Move the handle grip to the low speed position. When the engine idles at a very low speed, move the shift lever back to “F” (FORWARD). Reverse After the engine idles at a very low speed, move the shift lever forward to “R” (REVERSE). “R” (REVERSE, “F“ (FORWARD)
NOTE: Be sure to run the engine at a very low speed (idle) before moving the shift lever.
35
