METER
INSTALLATION
(I) Tachometer (EP type) Set the selector pointer to the “6P” mark on the back of the meter.
Install the meters in the dashboard so that they are easily seen and away from streaming water. A dashboard ranging from 2 to 11 mm (0.08 to 0.43 in) thick can be installed as required. If it exceeds a thickness of II mm (0.43 in), cut down the fitting plate accordingly.
(2) Mounting angle Install each meter at a mounting angle of SO0 to go0 as shown. NSW037A
23
