INSTALUlION
Stern bracket (1) While aligning the transom board with the mounting holes of the motor’s stern bracket, drill four holes on the board and tighten with the furnished Ml2 x 90 mm bolts. Refer to the outline dimensions of the stern bracket on page 14. (2) Before drilling the holes, secure the NSWOO9A transom board using a clamp to prevent misalignment.
470 660mm(18.50- 25.98 InI
OUTBOARD MOTOR Mounting position Mount the outboard motor on the centerline of the boat using cushion(s) or plate(s) as required. (Fig. 1) Mountfng height When two outboard motors are to be mounted on the boat, maintain a distance of 470 to 660 mm (18.50 to 25.98 in) between the two. (Fig. 2) After mounting the motors, maintain a distance of 0 to 30 mm (0 to 1.18 in) between the anti-cavitation plate and the bottom of the boat. l The location of the stem bracket may be shifted at an interval of 18 mm (0.71 in) on outboard motors equipped with the power trim& tilt. On the other models, it may be shifted at an interval of 25 mm
m (Figure 2)
NOTE: Apply a coat of silicone sealant to the drilled holes and bolts before tlghtening the nuts and bolts.
(Figure 3) NSWOO9A
Centerline
Of boat
(Figure 1)
13
