RG 200.B
MAIN DIMENSIONS M.
Distance from center of tandem to end of machine
5‘ 4“
(1637 mm)
N.
Distance from front axle to end of machine
25‘ 9“
(7856 mm)
O.
Overall machine length without front blade and rear ripper
27‘ 11“
(8521 mm)
P.
Distance from center of rear axle to end of ripper
6’ 7”
(2015 mm)
Q.
Distance from front tires to front scarifier
5’ 0”
R.
Distance from front tires to front blade
5’ 4”
(1620 mm)
Turning radius outside tires
23’ 9”
(7250 mm)
Ground clearance (rear axle)
14’ 9”
(380 mm)
Ground clearance (front axle)
24’ 5”
(622 mm)
(1520 mm)
CENTER OF GRAVITY POSITION
Filled with all fluids, including radiator coolant, hydraulic oil, full fuel tank and operator´s weight and ROPS cab. X= 4450 mm Y= 950 mm Y
x
Read the SAFETY RULES on the preceding pages for machine protection and the safety of employees
26
