SECTION IV - MAINTENANCE
4.14 WHEN REQUIRED Thoroughly read and understand the section “SAFETY PRECAUTIONS” of this MANUAL before operating or servicing the machine.
WARNING Be cautious of hot fluids and surfaces. Wear goggles, safety shoes, hard hat, work clothes, and work gloves to perform inspection and maintenance on this machine.
F14396
A. CLEANING RADIATOR CORES
CAUTION Direct contact of yourself with compressed air, steam and high pressure water causes injury. Make sure to wear the protective glasses, mask, safety cap, safety shoes, etc.
1. Open the left side cover and the cover under the seat, referring to section “MACHINE FAMILIARIZATION” “Open/Close Guard Cover” 2. Check the radiator fins for clogging with dust and mud. 3. Remove the dust and mud on the radiator cores and fins with compressed air.
NOTE: To avoid damages on the fins, take some distance between the spray nozzle of compressed air and the fins. If the fins gets some damages, it causes water leakage resulting in overheating.
120
F19389
