SECTION 10 - ENGINE
CODE
SHORT FAILURE DESCRIPTION
49
AMBER WARNING
RED STOP
One second alarm upon activation for key cycle
3219
Bank2 - Injection Cable Short circuit Low Side to Ground.
X
3221
Bank2 - Unclassifiable Error.
X
3227
Injection Processor (CY33X) Error - Internal Reset / Voltage Too Low.
X
3228
Injection Processor (CY33X) Error - Unlocked / Initialization Failure.
X
3229
Injection Processor (CY33X) Error Injections Limited By Software.
X
3230
Injection Processor (CY33X) Error - SPI Communication Failure.
X
3231
Injection Processor Error - Internal Reset / Clock Loss / Voltage Too Low.
X
3232
Injection Processor Error - Unlocked / Initialization Failure.
X
3233
Injection Processor Error - Test Mode.
X
3234
Injection Processor Error - SPI Communication Failure.
X
3238
ECM Internal SPI Communication Error - CJ940.
3242
ECM (Locked) Recovery Occurred.
3243
ECM Recovery (Suppressed) - Recovery Occurred.
X
3244
ECU Recovery (Visible) - Recovery Occurred.
X
3245
ECM Processor - Watchdog Not Plausible.
X
3246
Shutoff Paths During Initialization - Watchdog.
X
3247
Shutoff Paths During Initialization Supply Voltage Too High.
X
3248
Shutoff Paths During Initialization Supply Voltage Too Low.
X
3249
TPU Monitoring - Time Deviation between TPU and System Not Plausible.
X
3250
Dataset - Variant Defective.
X
3251
Dataset - Requested Variant Could Not Be Set.
X
3252
Controller Watchdog - SPI Communication Failure.
X
3253
ADC Monitoring - Reference Voltage Too Low.
X
3254
ADC Monitoring - Reference Voltage Too High.
X
3255
ADC Monitoring - Test Impulse Error.
X
X X
