Operation Load diagram The load diagram is located in the cab (front window) of the machine, values are calculated for the respective machine model – see Use: attachment on page 9. WARNING! If you exceed the maximum loads stated, the machine may become unstable. 24” (610 mm) load center: Rated operating load, standard bucket (SAE) - lbs. (kg.) 3748 (1700)
Printed in U.S.A.
94
Rated operating load, pallet forks (SAE) - lbs. (kg.) 3031 (1375)
