Operation Re-installing attachments Re-installing attachments is described below for the standard bucket. If you are fitting or removing attachments with their own hydraulic functions, you must follow the information provided in the Operator’s Manual of the attachment. Fitting attachments onto the quickhitch facility
WARNING! The attachment must always be locked onto the quickhitch facility –
Accident risk. ☞ Before working, be sure that the attachment is locked onto the quickhitch by
using the lock cylinder. Be sure that you can see the lock pins on both sides of the mounting holes on the attachment.
Re-install as follows:
C
☞ Drive the machine up to the attachment. ☞ Lower loader unit E by pressing control lever 10 forward C. ☞ Tilt the quickhitch facility forward by pushing control lever 10 to the right B. ☞ Adjust the height of pin shanks G of the quickhitch facility so that they are under catch
10
hooks F of the attachment.
B
☞ Drive the machine forward until pin shanks G of the quickhitch facility are directly beneath the catch hooks of attachment F.
D E
F
G
Fig. 85: Driving up to the attachment
☞ Raise loader unit E until pin shanks G engage in pin shanks F of the attachment. To do this: Pull control lever 10 rearward D.
E
C
☞ Fully tilt in the quickhitch facility. To do this: Push control lever 10
to the left A.
10
A H D Fig. 86: Raising the attachment
