Operation Operator's seat 21
22
26 307b0370.ai 307b0380.ai
24
Fig. 64: Seat adjustment
WARNING! Never change the seat position when driving or working –
Accident risk. ☞ Adjust the seat before moving the machine. ☞ Make sure the levers for seat adjustment are safely engaged. Weight setting
You can adjust the seat suspension to your weight in 9 levels, 110 – 287 lbs. (50 – 130 kg), with lever 22.
☞ Sit down on the operator’s seat. For a higher weight:
☞ Press lever 23 down 22 lbs. (10 kg) per notch. For a lower weight: 23 307b0360.ai
☞ Press lever 23 down to the lowest position. ➥ Weight setting automatically returns to the upper 110 lbs. (50 kg) position. ☞ Press lever 23 down to the required position.
Fig. 65: Weight setting
