REASSEMBLY NOTE:
Use bolt torque chart that follows to tighten bolts as steering unit is assembled. Bolt Torque Chart
1.
Bolt Size
Torque Value
M10
4.8 kg•m (35 ft. lbs.)
3/8 - 16 NC
4.8 kg•m (35 ft. lbs.)
Install springs in spool slot. See Figure 28. Springs must be positioned as shown in Figure 29.
Figure 28
Figure 29 2.
Position springs so that amount of spring protruding out of spool is equal on both sides. See Figure 30.
Figure 30
S0709730K Page 18
Power Steering Unit
