Return to Master Table of Contents 17.
Push neutral position springs out of groove in spool. See Figure 25.
18.
Remove dust seal from housing. See Figure 26. Remove O-ring and backup ring from inside housing.
19.
Figure 27, shows all parts removed from steering unit. Clean all parts before assembly. Use only new O-rings and seals.
Figure 25
Figure 26
Figure 27
CLEANING AND INSPECTION For general cleaning and inspection procedures, refer to "General Maintenance Procedures" section.
Power Steering Unit
S0709730K Page 17
