Pos.
Amp.
Colour
System / Component
F58
7.5 A
Brown
Front LH, rear RH side marker power supply from T23
F59
-
F60
7.5 A
F61 F62
Brown
+30 NSP
7.5 A
Brown
+30 T24 third stop
20A
Yellow
+30 NCA
F63
15 A
Light blue
+30 fuel tank door T25 relay
F64
7.5 A
Brown
Front RH, rear LH side marker power supply from T23
F65
20 A
Yellow
+30 NPP, NPG, NVB locks
F66
20 A
Yellow
+30 sunroof
F67
30 A
Green
Rear LH seat movement (from T21)
F68
-
F69
30 A
Green
Rear RH seat movement (from T21)
F77
20 A
Yellow
Power socket on armrest (from T21)
F78
20 A
Yellow
+30 power socket
F79
7.5 A
Brown
Rear seat movement (from T21)
F80
25 A
White
+30 bass box
-
6
If a fuse blows
