STABILIZER CYLINDER
000198 - STABILIZER CYLINDER Index Description Number 1 Nut, 1” NF Nylok 007712 (*) 2 Plug N/A 3 Oil Seal, 1-5/8 OD x 1-1/8 ID * 4 O-Ring, 1” OD x 3/4 ID * 5 O-Ring, 1-3/8 OD x 1-1/8 ID * 6 O-Ring, 2” OD x 1-3/4 ID * 7 O-Ring, 2” OD x 1-5/8 ID * 8 Leather Washer * 9 Back-Up Ring * 10 Back-Up Ring * 11 Retaining Ring * 12 Piston 904231 13 Gland 904232 14 Cylinder Tube Weldment 904810 15 Piston Rod Weldment 904785 Seal Kit (Items denoted with * , less Piston) 904260 For Complete Hydraulic Cylinder, order 000198 IMPORTANT - Replace cylinder Nut (1) any time nut must be removed, and torque to 140 Lb-Ft.
36
