MAINTENANCE AND SERVICE
1. Opening covers
2. Inspection items To prevent any possible failure, some items should be checked daily. Make sure to perform inspection before driving.
Hood Hood lock lever
► Inspection items T19O501A
T19O502A
① Slide the hook to the side. Then, the hood opens with a clicking sound.
② Lift the hood with hands. Then, the hood is automatically opened and fixed by its damper.
► Opening hood
Inspect each part in the following order: ① Check the items that were faulty yesterday. ② Go around the tractor and check: - Lamps for proper illumination and damage - Tires for inflation pressure, crack, damage and wear - Rotating parts for loose bolts and nuts - Transmission fluid level - Implement attachment status
5-
