WORK PROCEDURE
1. Precautions for handling implement (1) When driving the tractor to attach or detach an implement, make sure that there is no one in between or around the tractor and implement. (2) Install and remove the implement only on safe and level ground. (3) When installing a heavy implement, install weight on the front to keep balance. (4) When adjusting an implement, apply the parking brake, stop the engine and set the PTO switch in the OFF position in advance. (5) To tow anything, use the towing hitch only.
WARNING
• Read instructions on warning de-
cals on each implement thoroughly before work. • To avoid an injury due to mishandling of an implement, read the user's manual of the implement thoroughly and work safely and precisely with caution. • Installation of an improper implement can lead to an injury. Install only implements specified by the Manufacturer.
2. General implement ► Rotavator <Safety precautions for rotavator>
• Never remove the safety cover
of the rotavator. • Do not remove the PTO shaft cover and safety cover on the universal joint. • When adjusting each part, disengage the PTO and stop the engine in advance. • When driving on a road, keep the PTO disengaged. Also, keep the rotavator lowered on a road as long as it does not hit the ground. • For the universal joint, its inner shaft and outer shaft should be overlapped at least 5.9 in.(15 cm). • Check that the universal joint is firmly fixed to the tractor and rotavator shaft.
4-
