200 SETUP AND ADJUSTMENTS
Figure 7-2 — Flywheel Marks
2. Back off the valve rocker adjusting screws. 3. Loosen the No. 1 cylinder yoke adjusting screw locknuts. 4. Exert moderate force on the yoke by pressing on the rocker arm slipper end. Turn down the yoke adjusting screw until it makes solid contact with the outboard valve stem tip, as sensed by a light drag on the adjusting screw. 5. Turn adjusting screw an additional 1/6 turn (60 degrees) clockwise.
A 1/6 turn is equal to one flat on the adjusting screw locknut. 6. Hold the yoke adjusting screw in this position while tightening the adjusting screw locknut. Torque locknut to 33 lb-ft (45 N•m) using torque wrench J 24407 or equivalent. Figure 7-3 — Yoke Adjusting Screw and Locknut
Page 7-4
