200 ENGINE ASSEMBLY [261 CK] AIR COMPRESSOR Installation
If the oil supply tube is lost, the air compressor will fail from lack of oil.
Refer to Figure 6-75. 1. Install a new gasket on the air compressor mounting flange.
3. Install the three mounting capscrews (5) and torque to 70 lb-ft (95 N폷m) using torque wrench J 24407 or equivalent.
2. Check to ensure that the lubrication oil supply tube (2) is in place and position the air compressor (1) on the mounting flange.
1
4. Reconnect the coolant lines to the air compressor cylinder head.
2
5 4 3
200360a
Figure 6-75 — Air Compressor Installation 1. Air compressor 2. Oil supply 3. Auxiliary driveshaft
4. Oil drain openings 5. Capscrew
Page 6-65
