200 ENGINE ASSEMBLY 2
Clean any RTV from around the bottom of the cylinder sleeve and the block which may have been pressed between the block and sleeve during installation.
1 3
4
6
7. After the cylinder sleeve is fully seated, use depth gauge J 26948 or equivalent to check flange height above the deck dimensions. The specified flange height above-deck dimension is 0.022–0.027 inch (0.559–0.686 mm). The measurement should be taken in the channel between the sleeve top lip (fire dam) and the coining bead. Refer to the TROUBLESHOOTING section, Figures 9-1 and 9-2.
The height of the cylinder sleeves above the cylinder block deck (under the same cylinder head) can vary as long as all are within the 0.022–0.027 inch specification. 5
200279a
Figure 6-12 — Sleeve Installation 1. Crevice seal groove 2. Crevice seal 3. Sleeve
Page 6-12
4. Shims (as required) 5. Counterbore ledge 6. Cylinder block
