200 ENGINE ASSEMBLY 5. Check the bushing surface for burrs caused by installation. 1
Refer to the Fits and Limits chart in this manual for correct bushing ID dimensions.
2
6. Using an inside micrometer or telescope gauge, measure the ID of the bushing to ensure against using an undersize bushing. An undersize bushing may cause the auxiliary driveshaft to seize in the bushing during installation.
The front auxiliary driveshaft bushing must be flush or recessed within 0.020 inch (0.508 mm) of the front of the cylinder block. Incorrect recess will cause misalignment of the oil supply hole, resulting in insufficient lubrication of the journal.
3 4 200323a
Figure 6-11 — Auxiliary Driveshaft Bushing Alignment 1. Alignment mark 2. Bushing 3. Pilot adapter J 37713
Page 6-10
4. Camshaft bushing remover/installer kit J 21428-01
7. Working from the front of the cylinder block, repeat steps 1 through 6 to install front bushing.
