200 ENGINE ASSEMBLY INSTALLATION Refer to Figure 6-6. Each camshaft bushing is located at set distances from the thrust washer mounting surface to the forward edge of the bushings.
Correct installation of each camshaft bushing is very important. If a bushing is not properly aligned with both its oil supply and oil feed passages in the cylinder block, either the camshaft bushing will fail or the components lubricated by the bushing feed will fail from inadequate lubrication.
Figure 6-6 — Camshaft and Auxiliary Shaft Bushing Locations
Page 6-6
