200 BENCH PROCEDURES Econovance Disassembly
3. Remove inner shaft assembly from rear of Econovance housing by manually guiding gear assembly outward.
Refer to Figure 5-75. 1. Place scalloped drive hub (5) in a vise equipped with brass jaws. Remove drivehub retaining capscrew (10) and washer (9) while holding inner shaft assembly (2) at rear of Econovance. This will prevent assembly from dropping out of housing when retaining capscrew is removed.
4. Remove inner sleeve (4) from inner shaft assembly. 5. Remove and inspect Econovance spring (3) for cracks or signs of wear. 6. Remove outer shaft drive hub (5) from housing (8).
2. Using snap-ring pliers, remove snap ring (1) from rear of Econovance housing (8).
Figure 5-75 — Econovance Assembly 1. Retainer ring 2. Inner shaft assembly 3. Econovance spring 4. Inner sleeve 5. Outer shaft drive hub
6. Solenoid valve 7. Valve housing 8. Econovance housing 9. Washer 10. Drive hub retaining capscrew
Page 5-63
