200 BENCH PROCEDURES New cylinder heads have been produced in November 1996 which have 20-degree intake valves and seats. These valves and seats replace the 30-degree intake valves and seats in all E7 cylinder heads. The 20-degree valves and seats are 100% interchangeable with the 30-degree valves and seats, provided the seat matches the valve (20-degree seat with 20-degree valve, 30-degree seat with 30-degree valve). Remanufactured assemblies will use either 20-degree or 30-degree valves and seats on certain applications (never mixed in one head). See the following chart and figures to identify your assembly.
Reman Part No.
Angle
Assembly ID
Valve ID
20°
72
2
30°
24
I
20°
71
2
30°
52
I
20°
70
2
30°
51
I
732GB3466MX
20°
66
2
E7 engines (1994/95/96)
732GB3469MX
20°
69
2
1995/96 E7 engines for Jacob® Stealth™ retarding system applications.
732GB3424X
732GB3452MX
732GB3451MX
Page 5-44
Applications E6 4VH Engines
E7 engines (pre 1991)
E7 engines (1991/92/93)
