Figure 5-26 — New Valve Stem Seal
This new seal is recommended for all E7 engines. The single lip seal has been terminated, and as service stock is depleted, only the new seal will be available. This new seal can be used on the old-style valve guides. Part Number
Description
446GC328
Valve Stem Seal
446GC296
714GB3103
Valve Guide
714GB222
Page 5-26
Refer to Figure 5-27. 4. With valve spring keepers (1) removed, remove upper washer (2), valve spring (3), oil seal (4), lower washer (Roto-Coil) (5) and valve (6).
Replaces
After removing the valve springs, removal of the existing valve stem seals can be accomplished easily and quickly by using the J 39460 Valve Stem Seal Removal tool. Failure to use this tool could make seal removal more difficult, and could result in damaging the outside diameter of the valve guides.
