5 Maintenance 5.1 Maintenance access doors 5.1.1
Overview of access doors
Fig. 5-1
Access doors for maintenance on the machine
Pos.
Denomination / location of the door
Locking device in opened position
Locking device in closed position
10
Side door right rear
Retaining rod 3
Lock up handle 4
11
Side door right front
Retaining rod 3
Lock up handle 4
12
Air filter door
Gas pressure spring 5
Door fixed by screws
13
Side door left
Retaining rod 3
Door fixed by screws
21
Engine hood
Mechanical retainer 2 + two gas pressure springs 5
Locking device 6. Access after opening hood 25
22
Cooler cover
Gas pressure spring 5
Cover fixed by screws
