Control and operation
Operating manual
Transport
Danger! All work on the electrical system of the machine must be carried out by a trained electrician or specialist technician under the supervision of an electrician and in accordance with the electro-technical regulations. In case of an electrical machine and if required, remove the slip ring. If required, remove the catwalks.
Lifting gear
1 2
Slings Nut-screw drive
5 6
Securing rod Rear lifting gear 964 C
3 4
Rear lifting gear 974 C Nut-screw drive
7
Shackle
Front lifting gear Position the slings 1 at the bearing bores of the boom. Insert and secure the boom pins. Ensure that the pins fasten the slings 1. Rear lifting gear 964 C Position the rear lifting gear 6 at the rear of the uppercarriage. Insert the rear lifting gear 6 at the rear of the uppercarriage. Insert the securing rods 5 to the stops throught lifting gear 6 openings. Secure the securing rod 5 with the nut-screw drive 4. Attach and secure shackles 7.
