Control and operation
Operating manual
Installation and removal of attachment parts
Overview
Fig. 3-120 LIKUFIX 1
Protective cover on quick-change adapter
4
LIKUFIX hydraulic coupling on work tool
2
Protective covering on work tool
5
Alternative hydraulic coupling on work tool
3
LIKUFIX hydraulic coupling on quick-change adapter
Attaching and dismounting work tools Attaching and dismounting is carried out as described in the chapter “Hydraulic quick-change adapter”.
Fig. 3-121 Connecting LIKUFIX Please also note: Before attaching, remove the protective coverings on the quick-change adapter 1 and the work tool 2. Always keep hydraulic couplings 3 and 4 clean. Perform a visual check for cleanliness before attaching. If necessary, clean all coupling parts and the sealing surfaces with a clean, oil-soaked cloth.
copyright by
3 - 140
