Control and operation
Operating manual
Working with the machine
With the specified load, the machine can be rotated from 360° on even and horizontal ground.
Check of the overload warning system The overload warning system must be checked for correct function every time the machine is started and before load lifting work. Slowly extend the hoist cylinder to the stop. Operate the hoist cylinder to the stop. The overload warning status symbol appears on the display. An audio warning sounds in the operator cab. If a malfunction occurs: Do not lift loads. Have the overload warning system repaired.
Operation of the overload warning system DANGER! Tipping over of the machine! The overload warning system does not shut down the machine if the permissible load torque is exceeded. The operator of the machine is only informed of the situation. Death. Follow the safety instructions related to load lifting. Follow the instructions if the overload warning system is triggered. Push the key S18. The overload warning system is activated. The LED of the key comes on. If the overload warning system is triggered: – The overload warning status symbol is shown on the display. – An audio warning sounds in the operator cab. – The control elements of the machine continue to operate. Reduce the reach. or Lower the load to the ground without increasing the reach. Deactivation of the overload warning system NOTICE There is an increased pressure in the hydraulic cylinders during earth-moving operations! If the overload warning system is activated, it is triggered permanently. Switch off the overload warning system for earth-moving operations. Push the key S18. The overload warning system is deactivated. The LED of the key goes out of view.
copyright by
3 - 102
MJFCIFSS
R 974 C / 10069856
