Control and operation
Operating manual
Operating and control elements
actually), • the operation with the input X2.14 activated (special equipment – not used actually), • the operation with the Diesel engine at its standart power curve (at maximum power) Press the Menu key again. the screen 5/... is displayed.
Fig. 3-18
Menu "Info Hours" Data of the Master modul of the machine
This screen displays respectively: – the identification nb of the coding module – the Software Version of the Master module – the Checksum of the Master module Press the Menu key again. The screen 1/... is displayed. To exit the menu: Press the Back key. The sub-menu will be aborted.
Menu "Info In/Outputs"- Status of hydraulic pumps and of electrical inputs and outputs The screens 1 to 3 provide information on the regulation parameters for the hydraulic pumps.
Fig. 3-19
Menu "Info In/Outputs" Active flow and pressure limitations
The screen 1/... displays: – for each of the both working pumps the active flow limitation option and which percentage of the maximum flow is set (solenoid valves EV1 and EV2). – which is the active pressure limitation for the hydraulic system and which percentage of the maximum pressure is set (solenoid valve EV6).
copyright by
3 - 30
