Cylinder head
Tighten the ABS adjusting screw 5 with 0.3 Nm. ABS piston 9 goes to the limit stop. Tighten the ABS piston 9 with 45 Nm. Pull out the feeler gauge. Press on the ABS valve bridge 1 with your hand. ABS piston 9 goes to the limit stop. The push rod has play. The valve clearance for the ABS adjusting screw (optional) is set. Repeat the process for all cylinders.
Removing the turning device from the flywheel housing 2
1 3
Fig. 74: Removing the turning device from the flywheel housing Flywheel housing Turning device
3
External hex bolt (3x) LMB/01/19.03.2021/enus
1 2
Unscrew external hex bolt 3. Remove turning device 2 from flywheel housing 1.
