Group 1: Air Intake
Reproduced by permission of Deere & Company. E 1988 Deere & Company. All rights reserved.
Item 1 2 3 4 5 6 7 8
Part Number # GM24517 223532 GM17483 GM24516 # 360013 GM21508
Description Screw Manifold, intake Gasket Spacer Fitting O-ring, 8.1 x 1.6 mm Plug O-ring, 11.3 x 2.2 mm
Quantity Variation 1783 2 1 1 1 1 1 1 1
Reproduced by permission of Deere & Company. E 1988 Deere & Company. All rights reserved.
Item 1 2 3 4 5 6 7
Part Number GM18669 GM32781 GM32826 # GM24516 223532 GM17483
Description Clamp Hose Air intake Screw, M10 x 50 Fitting (includes O-ring) Gasket Spacer
Quantity Variation 1701 2 1 1 2 2 2 1
# Common hardware; procure locally.
10
TP-6290 3/14
