Group15: FuelLines

ReproducedbypermissionofDeere&Company. E 1988Deere&Company. Allrightsreserved.

Part

Item Number Description

1 # Screw,M10x20 2 GM32797 Bracket 3 360171 Clamp 4 # Flangenut,M10 5 223476 Sealingwasher 6 GM32814 Line,fuel 6 GM32833 Line,fuel 7 GM32831 Line,fuel 8 GM17494 Sealingwasher 9 — SeeGroup14 10 360178 O-ring 11 360015 Plug 12 360178 O-ring 13 360037 Adapter 14 — SeeGroup17 15 GM17494 Sealingwasher 16 GM32830 Line,fuel 17 — SeeGroup16

#Commonhardware;procurelocally.

Quantity Variation 6313 6366

1 1 1 1 1 1 1 1 3 3 1

1 1 1 4 4 1 1 2 2 2 2 2 2 2 2 1 1 4 4 1 1 1 1

ReproducedbypermissionofDeere&Company. E 1988Deere&Company. Allrightsreserved.

Part

Item Number Description

1 360015 Plug 2 360178 O-ring 3 GM34530 Adapter 4 360037 Fitting 5 GM17494 Sealingwasher 6 GM21453 Nut 7 GM52525 Fuelline 8 GM17470 Fitting 9 GM17471 O-ring 10 GM52526 Fuelline 11 GM32765 Screw 12 GM49832 Bracket 13 360171 Clip 14 # Flangenut,M10 15 GM32920 Fitting

#Commonhardware;procurelocally.

Quantity Variation 6386

4 1 1 3 1 1 1 2 2 1 1 1 1 1 1

Part

Item Number Description

16 GM32896 O-ring 17 GM50018 Fuelline 18 360141 Nut 19 223476 Packing 20 GM50037 Fitting,elbow 21 GM21508 O-ring 22 GM50079 Fuelline 23 223710 Plug 24 GM50026 Fitting 25 223912 Teefitting 26 GM52527 Fuelline 27 GM32830 Line,fuel 28 GM49918 Washer,sealing 29 GM32895 Fitting

Quantity Variation 6386

1 1 7 6 1 1 1 1 1 1 1 1 4 4
